XFX RADEON RX 9070XT SWIFT 16GB GPU Video Card RX9070XT

XFX Swift AMD Radeon RX 9070XT Triple Fan Gaming Edition – Specifications

Graphics Processor

• GPU Model: AMD Radeon™ RX 9070XT

• Stream Processors: 4096

• Compute Units: 64

• Boost Clock: Up to 2970 MHz

• Game Clock: Up to 2400 MHz

• Base Clock: Up to 1660 MHz

• Architecture: RDNA 4

• Process Technology: Chiplet Design

Memory Specifications

• Memory Size: 16 GB

• Memory Type: GDDR6

• Memory Bus: 256-bit

• Memory Clock: 20 Gbps

• Memory Bandwidth: 640 GB/s

Interface & Connectivity

• PCI® Interface: PCI Express 5.0 (x16)

• DisplayPort: 3 x DisplayPort 2.1

• HDMI: 1 x HDMI 2.1

• HDCP Support: Yes

Cooling & Power

• Cooling Solution: Triple Fan

• Heat Dispersal: Nickel-plated copper cold plate and heat pipes

• Fan Feature: Zero DB Fan (Fans stop at low load)

• Power Connectors: 2 x 8-pin

• Minimum PSU Recommendation: 800W

Physical Specifications

• Card Dimensions (L x H x W): 325 mm x 150 mm x 65 mm (12.8″ x 5.91″ x 2.56″)

• Slot Profile: 3.5-Slot

Supported Technologies

• AMD Software: HYPR-RX, Fluid Motion Frames, Anti-Lag+

• Upscaling: AMD FidelityFX™ Super Resolution 4 (FSR 4)

• Ray Tracing: Yes

• VR Ready: Yes

• Multi-Monitor Support: Yes (Up to 4 displays)

• AMD FreeSync™: Yes

• DirectX® 12 Support: Yes

• Vulkan® Support: Yes
