| Component | Specification |
|---|---|
| Model Number (Black) |
RL-KR28E-B2
|
| CPU Socket Compatibility | Intel LGA 1851, 1700, 1200, 115X; AMD AM5, AM4 |
| Warranty | 6 Years |
| Materials | Aluminum (radiator), Copper (cold plate), Plastic (housing/cap/fans), CIIR rubber with PET braided sleeve (tubing) |
| Software Control | NZXT CAM |
Pump & Water Block
| Attribute | Specification |
|---|---|
| Pump Name | NZXT Turbine Pump (Asetek pump mechanism) |
| Motor Speed | 800 – 2,800 ± 300 RPM |
| Power | 12V DC, 0.3A |
| Water Block Material | Copper |
| Cap Dimensions | 93.5mm Diameter x 65mm H (3.68″ x 2.56″) |
LCD Display
| Attribute | Specification |
|---|---|
| Panel Type | IPS LCD (Wide Viewing Angle) |
| Active Area | 2.72” (69mm) diameter |
| Resolution | 640 x 640 px |
| Brightness | 690 cd/m² |
| Refresh Rate | 60 Hz |
| Color | 16.7 million colors (24-bit true color) |
| Orientation | Software adjustable (Default, +90, +180, and -90 Degrees) |
Radiator & Tubing
| Attribute | Specification |
|---|---|
| Dimensions (L x W x H) | 321 x 137 x 27 mm |
| Material | Aluminum |
| Tube Length | 400 mm |
| Tube Material | Ultra-low Evaporation Rubber with Nylon Braided Sleeve |
Fans (F140 RGB Core Fans)
| Attribute | Specification |
|---|---|
| Quantity | 2 |
| Dimensions (W x H x D) | 140 x 140 x 26 mm |
| Speed | 500 – 2,000 ± 200 RPM |
| Airflow | 33.22 – 99.68 CFM (per fan) |
| Static Pressure | 0.91 – 3.2 mm H₂O (per fan) |
| Noise Level | 19.4 – 34.5 dBA (per fan) |
| Bearing Type | Fluid Dynamic Bearing (FDB) |
| Power Connector | 4-pin PWM |
