General
- Model numbers:
- V100X:Â Black, without ARGB fans.
- V100W:Â White, without ARGB fans.
- V100RX:Â Black, with four pre-installed ARGB fans.
- V100RW:Â White, with four pre-installed ARGB fans.
- Type:Â ATX Mid-Tower Case.
- Color:Â Black or White.
- Materials:Â Steel, plastic, and tempered glass.Â
Dimensions and clearance
- Case dimensions (L x W x H):Â 446mm x 235.5mm x 484.65mm.
- Maximum GPU length: 415mm–420mm.
- Maximum CPU cooler height: 178mm–180mm.
- PSU clearance:Â Up to 220mm.Â
Motherboard and expansion
- Motherboard support:Â E-ATX (under 246mm width), ATX, M-ATX, and Mini-ITX.
- Back-connect motherboard support:Â ATX and M-ATX.
- PCIe expansion slots:Â 7.Â
Drive bays
- 2.5″ SSD:Â 1 (behind the motherboard tray).
- 3.5″ HDD:Â 1 (in the bottom chamber).Â
Fans and radiator support
- Total fan capacity:Â Up to nine 120mm fans.
- Pre-installed fans (V100R models):Â 4 x 120mm PWM ARGB fans.
- Fan mounts:
- Top:Â 3 x 120mm or 2 x 140mm.
- Side:Â 3 x 120mm.
- Rear:Â 1 x 120mm or 1 x 140mm.
- Bottom:Â 2 x 120mm.
- Radiator support:
- Top:Â Up to 360mm or 280mm.
- Rear:Â Up to 120mm or 140mm.Â
I/O ports and features
- I/O ports:
- 2 x USB 3.0.
- 1 x USB 3.1 Type-C.
- 1 x Audio (combo jack).
- 1 x Power button.
- 1 x Reset button.
- RGB:Â Integrated 26-LED ARGB light strip with motherboard sync support.
- Panels: Dual 4mm tempered glass for a 270° panoramic view.
- Unique features:
- Includes a GPU support bracket to prevent sag.
- Includes a “display platform” for figures and collectibles.
- Dust filter:Â 1 x bottom dust filter.
