ADATA LEGEND 710 256GB | 512GB | 1TB | 2TB M.2 NVME Gen3 SSD Storage

ADATA LEGEND 710 M.2 NVMe Gen3 SSD Product Description

• Model Series: LEGEND 710

• Available Capacities: 256GB | 512GB | 1TB | 2TB

• Form Factor: M.2 2280

• Interface: PCIe Gen3x4

• NVMe Version: Supports NVMe 1.4

• Controller: Realtek RTS5766DL

• NAND Flash Type: 3D NAND (QLC / pQLC, varies by capacity and hardware version)

• DRAM Cache: None (Utilizes Host Memory Buffer – HMB technology)

• Sequential Read Speed (Max): Up to 2,400 MB/s (256GB: Up to 2,100 MB/s)

• Sequential Write Speed (Max): Up to 1,800 MB/s (2TB, 1TB) | 1,600 MB/s (512GB) | 1,000 MB/s (256GB)

• Random Read IOPS (4KB, Max): Up to 200K (2TB, 1TB) | 90K (512GB, 256GB)

• Random Write IOPS (4KB, Max): Up to 150K (2TB, 1TB) | 150K (512GB) | 130K (256GB)

• Terabytes Written (TBW) Endurance: 520TB (2TB) | 260TB (1TB) | 130TB (512GB) | 65TB (256GB)

• Mean Time Between Failures (MTBF): 1,500,000 hours

• Data Encryption: AES 256-bit Encryption

• Error Correction: LDPC (Low Density Parity Check) ECC

• Thermal Management: Includes aluminum heatsink (lowers temps by ~15%)

• Operating Temperature: 0°C to 70°C

• Storage Temperature: -40°C to 85°C

• Shock Resistance: 1500G/0.5ms

• Dimensions (with heatsink): 80mm x 22mm x 3.13mm (L x W x H)

• Dimensions (without heatsink): 80mm x 22mm x 2.15mm (L x W x H)

• Weight (with heatsink): 9g / 0.32oz

• Weight (without heatsink): 6.2g / 0.22oz
